Blackwood HTP Thermal Plates

Blackwood HTP-I Thermal Plates combine the qualities of a first-class aluminium base, with fine graining for even dampner distribution, together with a coating which has a high sensitivity, excellent plate adhesion and robust performance. The net result provides excellent dot reproduction, perfect ink/water balance and long run lengths for both commercial and newspaper applications.

Model
HTP-I Thermal Plate
Spectral sensitivity
830nm
Thickness
0.15~0.40mm
Sensitivity
120-400mj/cm2
Resolution
1-99% @350lpi
Run length
>100,000

Model
HTP-U Thermal Plate
Spectral sensitivity
830nm
Thickness
0.15~0.40mm
Sensitivity
110-130mj/cm2
Resolution
1-99% @350lpi
Run length
>100,000
Model HTP-I Thermal CTP Plate HTP-U Thermal Plate for UV Ink Printing
Spectral sensitivity 830nm 830nm
Thickness 0.15~0.40mm 0.15~0.40mm
Sensitivity 120-400mj/cm2 110-130mj/cm2
Resolution 1-99% @350lpi 1-99% @350lpi
Run length >100,000 >100,000
Developer DP-II DP-II
Develop temperature 24±1℃ 23±1℃
Develop Time 20-30 seconds 20-30 seconds
Replenishment rate Dynamic: 100-120ml/sqm
Static: 50-80ml/hr
Storage Temperature: 5-30℃; Humidity: 40-80% Temperature: 5-30℃; Humidity: 40-80%
Shelf life 18 months depending on storage conditions 18 months
Application Commercial, Packaging, Newspaper printing Commercial, Packaging printing, Newspaper printing, UV ink printing

NOTE: Run length will be effected by press, ink and paper conditions.
